The landing gear and wing leds are 0402 smds which I get pre-wired on ebay. I drill a hole to pass the wires through the gears, attach the leds with epoxy, and conceal them before closing the parts. I light block from the rear of the gears so they only light from the front I use some Humbrol masking fluid to protect the light outlets on the landing gear and the wings before painting. The wings are a bit tricky because you have to dremel out a channel for the wires and 0402 smds on the inside of both halves without drilling though the oiter side of the thin wings. I also light block the insides of the wings completely before sealing.

To light the engines, I used 4x 3535 smd neopixels for each engine. They are the smallest I could find measuring 3.5mm. Three of the neopixels are attached to 10x 0.25mm plastic optical fibers each. The fourth neopixel is for the main engine. I use a table vice and magnifying glass for soldering work, then I use 5 min epoxy for linking the smds together and to connect the fiber with some shrink tubing, a little trick I learned from NZEOD. I light block the neopixels with some polyeurethane primer so that the light only comes out the fiber and the main engine. All the 4 neopixels are controlled by one pair of wires led out of the completed leg part (neopixels actually have 3 wires each, unlike normal leds with a pair of wires). Part of the idea is to minimize the number of wires. To fit the wiring I also use the thinnest wires I can, such as 0.25 or 0.30mm enamel (magnet) wires. I use the clear parts again for the main engine to diffuse the 4th led, and I light block most of the part with black primer and metalic paint. I also drill some holes in the part to lead out the 30x strands of fiber. I blink the 4 separate leds at different colors and speed untill I get the effect I want. I then trim the fiber to the edge of the engines. I got this idea from an awesome Yamato Gun Gauge build. At the end of my above video you can also see that I use a bit of clear pla plate sanded down to diffuse the main engine led.

Up first is the cockpit WIP: I used the Hasegawa "Clear Version" Valk kit for the cockpit lighting. I masked off little squares for the side panels, then primed in black and painted many coats for light blocking. I then hand painted the panels in various clear tamiya colors. (Next time I would clear paint BEFORE masking and priming to get a cleaner finish). To get the side panels lit up I used a dremel to shave the sides of the canopy and used a strip of pla plate to create a little light box, which are light blocked with black and metallic paints. I find metallic steel to do a good job of light blocking. The leds are 0402 smds, less than 0.5mm width with a resistor for each led. For the cockpit panel lighting I scratched by hand a tiny little console with three panels sized to the Jasmin Models photo etch. You can see above the three panels and a clear pla plate sanded down to diffuse the light. Above is a test fitting before installing the photo etch and screens. All 5 pairs of wires are sent out the back and into the valk body to conceal them (6 pairs once I added the landing lights). Above I have installed the screen with panel details that comes with the Jasmin/Dream Model photo etch. At this stage they were perfect, but they are really easy to smudge in all the upcoming steps, and I managed to screw them up a bit in the end. But not a complete disaster. Above is the final installation of all photo etch parts and sealing/sanding of the cockpit to hide the seam lines. I ditch the Clear Valk from here on out, and start using only the normal kit, because painting a clear kit with lighting is a bad idea. (Still no smudges to screw up my cockpit panel. That comes later...) This is a shapeways 1/72 pilot. Had to chop his butt off to fit in there. What do you guys/gals think of the scale? Seems big to me, but I'm gonna go with it. I used RTK's amazing 1/72 masks for a clean finish. Highly recommended to avoid a nasty cockpit. Final paint and F-14 Diamondback decals. Worst decals I've ever used... had to lay each diamond decal down individually by hand, because the suckers disintegrated on me, but I'm not a perfectionist... Also wish I had painted the white circle decal screens rather than use the white decals provided by Hasegawa, before using the UN Spacy kite decal. As it is, I made a mess of it with three layers of decals. I'm not a good painter and no one should take advice from me, but this was my process: Mix white and gray lacquer Mr. Hobby airbrush surfacer primer. I use a mix because a gray primer will require a million coats of white base coat, so this makes it faster. Base coat is tamiya white with 5% gray of any sort. Then air brush gloss clear coat with Mr. Hobby Levelling thinner, before tamiya panel line wash. I also mix the panel line wash 50-50 gray and black so its not too dark. Then closed up with a satin clear coat. I code a simple sequence in arduino with a fade up and down. This is simpe stuff, anyone can learn it. These 3 tutorials got me started from nothing. I am not a tech or electronics guy in any way what so ever. https://learn.adafruit.com/lets-put-leds-in-things/from-scratch https://learn.adafruit.com/all-about-leds/overview https://learn.adafruit.com/adafruit-neopixel-uberguide/basic-connections

Thanks guys. Glad you like it. Still lots more to do to get it on the Prometheus

This is a new build to continue my motorized Ranger squadron, but this time I am using Xigfrid's Shapeways 3D printed gear. With Xigfrid's gear I got a much smoother operation, and in many ways an easier installation, although I can't say its ever that easy to cut into your valk like this. I also learned from my last build for the Motorized 1/72 VF-1S Launch Arm to pay closer attention to the type and speed of the motor as well as the coding to test full performance before final installation. In the last build I ended up with a slower motor speed than I expected. I also wanted to give a better step-by-step WIP with Xigfrid's gear, which will be coming up.

I highly recommend these. Got the cleanest finish ever on my 1/72 VF-1. No nightmare of cutting my own mask and scratching the canopy, no finger smuges from repeated handing, no problems at all.

Whoa! What a beast!

We need these competitions more often! Never saw so many Macross resin builds at one time. Awesome

And where will you store this...

And you think Im not working on that

Well, I learned from the best.

A little something I'm working on for you guys.

I have not used it, but knowing Mr. Surfacer primers, I am sure it will spray down nice and fine. Usually I warm up my primer spray cans in a pot of off-the-boil water for 15 seconds shake and repeat three times. For your Q-Rau I suggest doing one limb at a time if possible.

You know my feelings on that

"Absolute Realism"

I'm thinking of using pantyhose as mesh, what do you think? Also thinking of using reed switches for the garage roller limits. But have not tested yet if it will be reliable. I thought that the garage roller may not hit a normal limit switch well.

Nice trick!

Nice to see an old school anime build pop up here. I assume Hasegawa is now using advanced 3d modeling for their kits, which is why you are comparing them to Bandai. I also assume they had no such thing when they first did the questionable F-14s and the Vf-1s. And I see what you did with that masking guide. Lesson learned! Mechtech, Gosh, I'm also working on a rolling garage door. But it is just not fair how smooth your finishes are. What kind of mesh did you use, how did you make the gear box, and will you install limit switches?
